P-WTL-125-BGX Spring rewind hose reel for 8m of 6mm Oxy/Acetylene hose
- Series: P-W Series
- Model: P-WTL-125-BGX
In order to maintain the best possible pricing and accurate lead times we offer all of our customers tailored made quotations.
Once we received your request we aim to get back to you asap
P-W Series spring driven “Welding” reels are the ideal solution for managing bulky twin line welding hose.
- Compact design makes it better for shorter lengths of hose used in welding bays and brazing rooms
- The guide arm is adjustable to multiple positions, allowing for the ideal height setup for efficient use, and this reel can be easily installed on the ceiling, wall, or floor.
- Heavy duty CNC spun and ribbed discs offer greater strength and drum integrity compared to other reels and the ribbed edges increase safety for the operation if they ever touch the discs while returning the hose
| Type | |
| Rewind Method | Spring |
| Hose | |
| I.D. (Inside Diameter) | 06mm (1/4") |
| Length (m) | 8 m |
| Pressure (BAR) | 14 |
| Type of Hose | Call for Details |
| Supplied with Hose | No |
| No. of Hoses | Dual/Twin Hose |
| Application | |
| Media | Oxy/Acetylene |
| Construction | Steel |
| Weight | 18 |
| Dimensions (mm) | See Downloads Tab |
| Max. Working Temp. | 65°C |
| Swivel | |
| Seals | Viton |
| Material | 2 - Dual Port Brass |
| Connection | |
| Inlet | 1/4" BSPT |
| Outlet | 1/4" BSPT |
